Airlift Nissan 350Z 03-08 Performance Air Ride System 75520 /75620 AP Manual/3S/3P/3H

Airlift Nissan 350Z 03-08 Air Suspension

75520
Availability: CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Shipping: International Shipping is available. For quote email STEVE@D2BDMOTORWERKS.COM with your full name, house number, street name, city, province, country, and postal code. Free Shipping in 48 continuous states only.
Pricing: $0.00

Customize Your Item

- Airlift Front Performance Struts -
 * required
- Airlift Rear Performance Struts -
 * required
- Select Air Management -
 * required
- Select -
 * required
- SELECT -
 * required
- Select -
- Select -
 * required
- Select -
- Select -
 * required
- Select Size -
 * required
Qty:
Free Shipping!

Description

If you own a 350z, then you appreciate all of the things that make up a sportscar: great handling, sexy looks and a wonderful engine sounds! The Z has a great heritage and is a solid platform to build a modified car. And when it comes to lowering your ride, you have plenty of choices out there. Problem is, none have the versatility to get you the lowest slam height possible AND the handling that you expect from a sportscar. That is everyone but Air Lift Performance…

Air Lift Performance has created the perfect suspension kit to tear up a racetrack or stop people dead in their tracks at a show. As the leader in aftermarket high-performance air suspension, we know what it takes to perfectly balance ride, handling and stunning good looks. The engineering team involved in the design and development of these kits are real car guys that has over 35 years of road racing experience as drivers, engineers and crew. Performance is not just in our name, it’s in our blood.

So, what does it take to have such a versatile suspension? It all starts with having a strong foundation. In this case, the struts: Air lift uses 30-way adjustable, monotube struts with a serious range of damping adjustment that have been specially tuned to match the air springs. Monotube construction is the preferred choice in racing and for us for its sensitivity to small inputs as well as the great ability to shed heat when pushed to the limit. The 30 clicks of adjustment aren’t just for fun, but rather allow the user to dial in his preferred handling feel or desired ride quality. The range goes from super stiff to really soft, adjusting rebound and compression together, but with proportionally more rebound. And the struts weigh considerably less than the coil spring parts you remove, reducing unsprung weight: a benefit to both ride and handling.

Another notable feature is T-6061 aircraft aluminum upper mounts that are built around Japanese manufactured pillow ball bearings for long life and low noise and the quickest damping response.

What sets these struts way apart from the coil crowd is the addition of our adjustable, progressive rate air springs. These high-rate springs create a stable platform for aggressive track driving while providing a level of comfort not typically found with lowered suspensions. By using this progressive nature of air springs and maximizing available suspension travel, we are able to ride low without the punishing ride. And since they allow ride height to be adjusted with a button, no longer do you suffer the curses of static suspension lowness! No issues with speed bumps or steeply angled drives. Raise it up as high as stock to ride off-road without damaging the underbody. And think how easy it is to load it on the trailer or get your jack underneath.

Having good components in a kit is important, but making sure they work together to give the desired result is just as critical. Extensive testing at various race tracks and autocrosses proved important to creating the proper handling balance that makes this car so fun to drive! This kind of abuse also illustrates the toughness and durability of the parts when pushed to the limit.

But that’s not all. Before a kit makes it to the track, the components are torture tested on our hydraulic test rig for over 1 million cycles, simulating a real-world 100K miles. And as an ISO 9000 certified company, Air Lift is committed to quality disciplines and continuous improvement in all areas which translates to the best experience for the customer.

Perhaps you are worried about installation? To ease your mind, every kit comes with a detailed instruction manual to guide you through all the steps. If you can install suspension and wire a stereo, you have the skills necessary to make it happen. And if you have questions, or a problem, our industry leading customer service department will take good care of you.

You have a great car. Give it the best suspension upgrade possible that is at home on the street, the show field and the track! CHECK OUT THE VIDEO OF THIS KIT IN ACTION AT THE TRACK BELOW!!! YEAH BABY! PLUS THE V2 DIGITAL CONTROL SYSTEM TUTORIAL VIDEOS


HERES THE SPECS!
**30-level damping adjustable monotube front struts and rear shocks
**Double bellows springs
**Anodized red aluminum accents
**Threaded lower mounts on front struts
**No cutting or chassis modification required
**Drop Front: 80mm/ 3.15” (on NISMO edition 350z.)
**Drop Rear: 112mm/ 4.4” (on NISMO edition 350z.)
**Large range of damping adjustment
**Racetrack tuned handling
**All struts/shocks dyno tested & matched
SEE DOCUMENTS BELOW FOR INSTALL PDF'S

ALWAYS FREE SHIPPING IN 48 STATES WITH D2BD MOTORWERKS!






SEE BELOW FOR KIT SPECS:

Air Lift Performance 4-Way Manual Air Management System

Economical, simple and accurate control for all 4 wheels
Great for use with gauge and pillar pods
The system provides a maximum pressure of 200 psi
Features a VIAIR 100% duty cycle 16444 Compressor
1/4 air line for accurate and smooth adjustment
Attractive stainless steel switch plate

This Kit Includes:

Viair 444C Chrome Continuous Duty Compressor (200psi)
4 Gallon Raw Aluminum Tank
Air Line
Two Dual-Needle Pressure Gauges
4 Paddle Valves
Air Fittings
Air Line Cutter
Everything needed for installation!


Airlift 3P:

We asked ourselves: what would the ultimate air suspension be like? How would it combine an easy-to-use, reliable, and feature-rich system with powerful technology and beautiful design? Air Lift Performance 3P is the result of three years of development and testing. It is the most advanced product we have ever created.

Air Lift Performance 3P combines pressure-based control with the ability to add ride-height sensing technology with the upgrade to height sensors. While both types of air management have been utilized before, this is the first product to harness the benefits of both systems – instantly improving suspension control, performance, and vehicle ride flexibility.

This Kit Includes:

3H/3P digital controller
Integrated ECU + manifold
Advanced electrical wiring harness
60 ft. of 1/4th or 3/8th
Auto-draining inline water filter
All wiring, fuses, hardware, etc. required for installation
Your choice of lightweight aluminum air tank in raw or polished finish
All required tank fittings for installation
VIAIR 444C Air Compressor

2 YEAR WARRANTY


Airlift 3H:

We asked ourselves: what would the ultimate air suspension be like? How would it combine an easy-to-use, reliable, and feature-rich system with powerful technology and beautiful design? Air Lift Performance 3H is the result of three years of development and testing. It is the most advanced product we have ever created.

Air Lift Performance 3H combines pressure-based control with ride-height sensing technology. While both types of air management have been utilized before, this is the first product to harness the benefits of both systems – instantly improving suspension control, performance, and vehicle ride flexibility.

This Kit Includes:

3H/3P digital controller
Integrated ECU + manifold
Advanced electrical wiring harness
4 height sensors with wiring and mounting hardware
60 ft. of 1/4th or 3/8th air line
Auto-draining inline water filter
All wiring, fuses, hardware, etc. required for installation
Your choice of lightweight aluminum air tank in raw or polished finish
All required tank fittings for installation
VIAIR 444C Air Compressor

2 YEAR WARRANTY
